GEFERTEC Arc405

Manufacturer : GEFERTEC

Advanced 3D Metal Printers designed for industrial WAAM manufacturing. This series seamlessly integrates the well-established arc-welding method with CAD drawings from product designers and engineers, creating an innovative production system. Boasting either 3 or 5 motion axes, it provides unparalleled flexibility in component volume and facilitates the additive production of high-quality metal parts.

Key Features

  • Process monitoring through a built-in camera
  • Ground-level machine access with a sliding working table for effortless crane-assisted loading and unloading
  • Actively cooled base plate
  • Soundproof housing
  • Integrated case ventilation and welding fume extraction
  • User-friendly control unit
  • Incorporation of high-end components from renowned manufacturers
Reference : M230214-C
Location : EUROPE

No responsibility whatsoever is assumed with respect to technical description, quality, dimensions, year of manufacturing and completeness of machines.

The descriptions are made under full reserve of potential errors which will be without any influence on a concluded sale

rea-securite
Validated & certified by Multistation
Do you need more information ?
Call me back
Request a quote

Gefertec Arc405 5-Axis WAAM printer

  • YOM 2018 – refurbished by the manufacturer in 2022

It is utilising the Fronius TPS 400i PULSE welding torch and is running the control software on a SIEMENS 840Dsl system. The HMI is accessed via the integrated control panel with additional industrial keyboard, allowing the safe operation of the machine directly from outside the build chamber.

  • Working space : x 495 x y 680 x z 730 mm

The welding table has an integrated cooling system and a clamping area of 400mm diameter with a maximum payload of 200kg. It has a swieveling range between -95° and 10°, the rotating range is unlimited.

  • Machine total number of hours:  only 8000 working hours

Materials: ER70S-6 / ER CuAl-A 1 / Ti6Al4V / Union AlMg4,5Mn / AM Print 625 / AM Print 316L / Union X96 / 3Dprint AM 304L / AM Print 2209 / Thermanit 18 17 E Mn / UTP A34 / Union K 56

  • Machine dimensions: 2300 x 3000 x 3000 mm³

Ref.: M230214-C

Materials :
ER70S-6
ER CuAl-A 1
Ti6Al4V
Union AlMg4,5Mn
AM Print 625
AM Print 316L
Union X96
3Dprint AM 304L
AM Print 2209
Thermanit 18 17 E Mn
UTP A34
Union K 56

Type/Model : Arc405

YOM : 2018-2022

Building volume : 495 (X) x 680 (Y) x 730 (Z) mm³ / 400mm diameter clamping area

Process : Other Additive manufacturing

Number of hours : 8000

Condition : Very good condition
