Additive-Manufacturing

ADMATEC – Admaflex 130 Evolution

Manufacturer : Admatec
Sectors : Aerospace, Automotive, Education, Industry, Jewelry, Defense

The Admaflex 130 Evolution is suited for 3D printing both ceramic as metal parts. The Admaflex 130 Evolution is set up with an open architecture, providing layer-to-layer control to define printer settings. The open architecture also enables using in-house developed materials.

Reference : ADMATECadmaflex130
technique
Support
rea-paiement
Secure Payment
Do you need more information ?

Admaflex 130 Evolution : A multi-material 3D printer

Two materials, one machine, the Admaflex 130 Evolution is suited for 3D printing both ceramic as metal precision parts. Through an optional add-on, the ceramic 3D printer is suited to print metals too. This unique add-on supports high dense materials in staying homogeneous throughout the printing process, to optimize each layer. The advanced patented Admaflex Technology has an innovative material reconditioning system to minimize waste to none.

High resolution

The integrated DLP light engine allows for large surface printing, while maintaining precision and resolution, to produce even the smallest sized features in full detail.

Open architecture

The Admaflex 130 is set up with an open architecture, providing layer-to-layer control to define printer settings, easily accessible through an adaptive touch screen.

Customized materials

Though AdmaPrint products achieve the best printing results, the open architecture also enables using in-house developed materials.





Printing technology : DLP

  • Net printing building volume before sintering (by resolution) :
    90 x 56 x 110 mm (35 μm)
    160 x 100 x 110 mm (62.5 μm)
  • Layer thickness : 15 – 100 μm
  • Materials : Aluminum oxide 316L
    Zirconium oxide 17-4-PH
    Silicon dioxide
    Inconel 625
  • Final product density equal to CIM/MIM : Ceramics >98.5% Metals >96 %
  • Machine dimensions : 575 x 880 x 1760mm
  • Weight : Approx 300 kg
  • Required working temperature : 22 +/- 2°C
  • Relative humidity : < 40%
  • Power requirements : 110 / 230 V
  • File compatibility : SLC

Manufacturer

Admatec

A Ceramic and Metal additive manufacturing solution. Admatec is dedicated to provide additive manufacturing solutions for high demanding applications and markets. With the revolutionary ADMAFLEX technology, Admatec offers customers the ability to shape ceramics and metals from single piece to large scale productions. The ADMAFLEX process delivers strong performing materials…
